HSB Series Color LCD Display v
Preface
This handbook covers the radar and chart aspects of the following HSB Series
systems from Raytheon:
Note: Radar systems are supplied with an appropriate Raytheon scanner unit
and inter-connecting cable. Details for installing the scanner are described in
the Pathfinder Radar Scanner Owner’s Handbook.
The Raychart (RC) display units include a cartridge holder assembly which
contains two slots for C-MAP NT chart cards.
This handbook contains very important information on the installation and
operation of your new equipment. In order to obtain the best results in
operation and performance, please read this handbook thoroughly.
Raytheon’s Technical Services representatives or your local dealer will be
available to answer any questions you may have.
TFT LCD Displays
The colors of the display may seem to vary when viewed against a colored
background or in colored light. This is a perfectly normal effect that will be
seen with all color LCD displays.
In common with all Thin Film Transistor (TFT) LCD displays, the screen may
exhibit a few (less than 20) wrongly illuminated pixels. These may appear as
black pixels in a light portion of the screen, or as colored pixels in black areas.
CAUTION:
To provide protection against the damaging effects of UV light, it is
advisable to replace the sun cover provided when the color LCD display is
not in use.
System Display Scanner Chartplotter
Pathfinder Radar RL70C, RL80C Yes No
Raychart Chartplotter RC530, RC631 No Yes
Combined Pathfinder Radar/Chartplotter RL70CRC,
RL80CRC
Yes Yes
Repeater Display
Repeater Display
Repeater Display
RL70C, RL80C
RL70CRC,
RL80CRC
RC530, RC631
No
No
No
No
Yes
Yes
