Chapter 2: Getting Started & Adjusting the Display 2-33
Displaying the
Radar and
Synchronizing
Radar & Chart
FIND SHIP MORE!SCREEN
RDR CHRT
GOTO MORE!ROUTE
RDR CHRT
6
5
7
Press the soft key to synchronise the
chart & radar images.
The radar and chart windows are
synchronised and the cursor is
'homed' on the vessel
D4293-1a
Press the soft key.
See:
2.3 Controlling the Display
6.5 Cursor Echo
7.3 System Parameters
7.6 Chart Set Up
4
2. Press the soft key.
3. Press ENTER twice.
1. Move selection bar over
Radar/Chart Synch.
Move the chart cursor -- you can see
chart cursor move on the radar
screen.
You can move the cursor over
a radar target to determine its
identity on the chart
