3-28 HSB Series Color LCD Display
Using MARPA
3. Press the
MARPA BOX ON/OFF
soft key again to toggle the data box off.
➤ To view the MARPA database list and a target data box:
1. Press
MARPA
followed by the
MARPA LIST
soft key, the database list is dis-
played.
2. Use the trackpad to select a target, then press the
MARPA BOX ON/OFF
soft
key to toggle the data box on/off.
3. Press CLEAR to remove the database list.
Figure 3-16: MARPA Database List
➤ To cancel all targets:
1. Press
MARPA
followed by
MARPA LIST
to display the database list.
2. Press the
CANCEL ALL
soft key. You are prompted to confirm.
Press
YES
to continue, all the MARPA targets are cleared from the screen,
and the data is removed from the MARPA database list.
Press
NO
to cancel the operation.
MARPA
LIST
MARPA BOX
OFF ON
D4121-1
MARPA
ID BRG RANGE COURSE SPEED
0 327
o
T 0.63nm 256
o
T 3.0kts
1 537
o
T 1.70nm 256
o
T 2.0kts
CANCEL
TARGET
CANCEL
ALL
MARPA BOX
OFF ON
MARPA BOX
OFF ON
CANCEL
ALL
