Page #145 background imageLoading...
Page #145 background image
Chapter 7: Setting Up the System Defaults 131
7.4 Radar Set Up Parameters
The RADAR SET UP option allows you to set up the radar according to your
system configuration and your personal preferences.
Note: Some parameters can only be changed if you are using the Master
display (that is, the display to which the scanner is connected).
The following table lists the Radar Set Up parameters and their options, shows
the factory default setting, and provides a space for you to make a note of your
new default setting. Each parameter is described in the following subsections.
Parameter Options Factory New
Default Default
EBL DISPLAY MAG/TRUE RELATIVE
RELATIVE
TIMED TRANSMISSION OFF OFF
ON
TRANSMIT PERIOD 10 scans 20 scans
20 scans
30 scans
STANDBY PERIOD 3 minutes 10 minutes
5, 10 or 15 mins
DEFAULT MARK Fish, skull, X
SYMBOL X or anchor symbol
MARK DISPLAY OFF ON
ON
CLEAR MARKS Press soft key to clear N/A
marks database
CUSTOM SCALE OFF OFF
ON
SET RANGES...
BEARING ALIGNMENT Slider value 0°
EBL Display
The mode of the bearing data displayed for Electronic Bearing Lines (EBLs).
The bearing information can be displayed in either of two forms:
Relative: The bearing relative to your vessels heading.
Mag/True: The actual bearing in either degrees magnetic or degrees true.
This option is only available if you are obtaining data from a compass.
Radar Set Up
Parameters
