148
HSB Series LCD Display
For further details on the master display power cable length refer to the
Pathfinder Radar Scanner Owner’s Handbook.
Inter-Unit Cable
The inter-unit cable entrance is at the rear of the scanner unit. If the unit is
mounted on a hollow mast the cable may be run inside the mast and then fed
through the radar’s cable entrance. Make sure that the cable does not chafe
where it enters the mast.
Note: Route the cable from the display up to the scanner, since this will require
the smallest clearance hole.
The type of inter-unit cable, for connecting the scanner to the display unit,
depends on your scanner package. Refer to the Pathfinder Radar Scanner
Owner’s Handbook for details, which include length considerations and
bending radii.
Inter-Unit Cable
