Appendix C: C-MAP Chart Features 187
Appendix C: C-MAP Chart Card Features
The C_MAP chart cards display cartographic features which are derived from a
library of symbols. The library includes a set of 16 x 16 pixel bitmaps which
provide realistically shaped icons for many chart objects. However, these
complex icons can overlap and clutter the display at some scales, so it possible
for the user to select smaller, simple icons. Some chart objects are represented
by text; in such cases conventional abbreviated text is used, for example, M –
mud, Sh – shingle, R – rock.
The chartplotter RC520 and RL70RC set up menu provides the sub-menu
CUSTOMISE CHART, which lets you determine how chart features are displayed.
You can set the icon display of many features to custom; you then use the
CUSTOM soft key to switch the customised icons off/on. The factory default for
the CUSTOM options is on.
The chart features controlled from the Customise Chart menu are grouped as
detailed below, some groups are sub-divided into categories
Menu Option Chart Features
CHART TEXT Names
CHART BOUNDARIES Chart Boundaries
SPOT SOUNDINGS Spot Soundings
DEPTH SHADING LIMIT Reference Depth
DEPTH CONTOURS Depths (Bathymetric Lines)
Depth Labels
DEPTH CONTOUR DISPLAY Depth Contour Range
NAV MARKS
Lights:Lights:
Lights:Lights:
Lights:
Buoys and Beacons:Buoys and Beacons:
Buoys and Beacons:Buoys and Beacons:
Buoys and Beacons:
SignalsSignals
SignalsSignals
Signals
Light; Buoy, cardinal Anchor
Light moire’ effect; Buoy,installation Cairn
Light float; Buoy, isolated danger Chain/Wire
Light vessel Buoy, lateral Fog signal
Buoy, safe water Radar reflector
Buoy, special purpose Top mark
Buoy, generic Nav aid, generic
Beacon, cardinal Extended nav-
Beacon, isolated danger -aid, generic
Beacon, lateral Radar station
Beacon, safe water Radar trans-
Beacon, special purpose -ponder beacon
Beacon, generic Radio station
LIGHT SECTORS Light Sectors
Appendix C:
C-Map Chart Card
Features
