HSB Series LCD Display
Console Mounting
The display unit can be console mounted if required, using the optional flush-
mounting kit (M92708).
CAUTION:
Make sure there are no hidden electrical wires or other items behind the
location before proceeding. Make sure there is sufficient rear access for
mounting and cabling.
1. Check the selected location for the unit. A clear, flat area at least 230 mm
(9 in) wide by 210 mm (8¼ in) high, with at least 152 mm (6 in) of
clearance behind the panel, is required.
2. Unpack the flush-mounting kit.
3. Using the supplied template, trace out the display unit opening.
4. Drill a 12.7 mm (½ in) pilot hole in each opposing corner of the
cut-out area.
5. Using a suitable saw, cut along the inside edge of the cut-out line.
6. Remove the trunnion (yoke) knobs and bracket from the display unit. Make
sure that the unit fits in the cut-out area.
6a. If the optional screw fitting is required, drill four 5 mm holes as indicated on
the template.
Screw the studs into the holes provided at the rear of the display.
7. Connect the DC power cable, inter-unit cable, and any other accessory
cables to the display avoiding tight bends in the cables.
8. Place the gasket on the unit and slide the unit into the panel cut-out.
9. Use the flush-mounting kit to secure the unit to the console. Fitting of the
trunnion ratchets is shown on the template drawing.
9a. Alternatively, fit a spacer over each of the four studs and secure with the
thumb nuts.
Console Mounting
