144

HSB Series LCD Display

8.2 Unpacking and Inspecting the Components

Unpack your system carefully, to prevent damage to the equipment. It is good

practice to save the carton and packing for future use, in case you need to return

any units for service.

Check that you have all the correct system components. These depend on your

system package, as follows:

ItemItem

Item

Part No.Part No.

Part No.

Supplied with:Supplied with:

Supplied with:

Option for:Option for:

Option for:

7” LCD Display7” LCD Display

7” LCD Display M92662 Light grey: RL70 -

M92732 Dark grey: RL70 -

M92670 Light grey: RL70RC -

M92733 Dark grey: RL70RC -

R32005 Light Grey: RL70RC -

R32007 Dark Grey: RC520 -

7” LCD Display Accessories7” LCD Display Accessories

7” LCD Display Accessories

Sun cover (light grey) D331 Light grey: RL70, -

RC520, RL70RC -

Sun cover (White) D356 Dark grey: RL70, -

RC520, RL70RC -

Handbook, Radar/Chart 81163 All -

Quick Reference Card, Radar 86032 RL70 RL70RC -

Quick Reference Card, Chart 86033 RC520, RL70RC -

Mounting bracket assy. W143 All -

Trunnion knobs (x2) W145 All -

Flush mount kit M92708 - All

Power cable W144 All -

Seatalk cable assembly

Flat moulded plugs both ends:

1 m (3 ft 3 in) long W284 - All

3 m (9 ft 9 in) long W285 - All

5 m (16 ft 3 in) long W286 - All

9 m (29 ft 3 in) long W287 - All

Flat to male round connector:

0.3 m (12 in) long D187 - All

Flat to female round connector:

0.3 m (12 in) long D188 - All

Flat moulded plug one end only:

1 m (3 ft 3 in) long D229 - All

Ferrite clamp R55007 - All

Seatalk junction box D244 - All

Seatalk auxilliary junction box R55006 RC520, RL70RC -

HSB cable assy

- 1 m (3 ft 3 in) R55001 - All

- 3 m (9 ft 9 in) R55002 - All

- 6 m (19 ft 6 in) R55003 - All

- 10 m (32 ft 6 in) R55004 - All

NMEA OUT cable assy.

1.5 m (4 ft 11 in) R55005 All -

Unpacking and

Inspecting the

Components
