Appendix A: Specification
HSB Series 7" LCD Displays
General
Approvals
CE - conforms to 89/336/EEC (EMC), EN60945:1997
FCC - conforms to Part 80 (47CFR) and Part 2 (47CFR)
Size 222 x 204 x 75 mm (8.8" x 8" x 3"), excluding bracket
Weight 1.2 Kg (2.6 lbs)
Mounting Trunnion with panel mount option
Power External 10.7 - 44 V DC required
10 W consumption with full backlighting
Floating earth/fully isolated
Environmental Waterproof to CFR46; suitable for external mounting
Temperature range: -10°C to +70°C
Humidity limit: up to 95% at 35°C
Controls 11 defined keys, 4 soft keys and trackpad
Cursor Context sensitive, provides range/bearing or lat/lon
Display Type 7" Film Super Twist Neumatic
(FSTN) LCD,
monochrome with 4 grey scales
Resolution 320 x 240 (¼VGA) portrait
Display Size 7" diagonal (143 x 111 mm)
LCD Contrast 64 levels, selectable via soft keys.
Illumination Screen: 8 levels of backlighting
Keypad: 3 levels of backlighting
Languages UK English, US English, Danish, French, German,
Dutch, Italian, Norwegian, Portuguese, Spanish,
Swedish, Finnish
Connectors 13 pin scanner
3 pin HSB input/output
3 pin SeaTalk input/output
7 pin power including 2 NMEA input channels
4 pin NMEA output
Interfaces 1 x SeaTalk, receive and transmit
1 x HSB, receive and transmit
2 x NMEA 0183, receive
1 x NMEA 0183, transmit
C-MAP cartridge reader - 2 slots (RL70RC and RC520)
