Preface iii

Preface

This handbook covers the radar and chart aspects of the following HSB Series

systems from Raytheon:

SystemSystem

System

DisplayDisplay

Display

ScannerScanner

Scanner

ChartplotterChartplotter

Chartplotter

Pathfinder Radar RL70 Yes No

Chartplotter RC520 No Yes

Combined Pathfinder

Radar/Chartplotter RL70RC Yes Yes

Repeater Display RL70 No No

Repeater Display RL70RC No Yes

Repeater Display RC520 No Yes

Notes: Radar systems are supplied with an appropriate Raytheon scanner unit

and inter-connecting cable. Details for installing the scanner are described in

the Pathfinder Radar Scanner Owner’s Handbook.

The chartplotter display unit includes a cartridge holder assembly which

contains two slots for C-MAP NT chart cards.

This handbook contains very important information on the installation and

operation of your new equipment. In order to obtain the best results in operation

and performance, please read this handbook thoroughly.

Raytheons Product Support representatives or your local dealer will be

available to answer any questions you may have.

Warranty

To register your HSB Series display unit ownership, please take a few minutes

to fill out the warranty registration card found at the end of this handbook. It is

very important that you complete the owner information and return the card to

the factory in order to receive full warranty benefits.

EMC Conformance

All Raytheon equipment and accessories are designed to the best industry

standards for use in the leisure marine environment.

When powered up, all electrical equipment produces electromagnetic fields.

These can cause adjacent pieces of electrical equipment to interact with one

another, with a consequent adverse effect on operation. In order to minimise

these efffects and enable you to get the best possible performance from your
