Generally authorised speed settings
The default values of low-energy operators for authorised speeds are shown in the EN
16005. They are calculated depending on door leaf weight and door width, in which the ki-
netic energy of a moving door should not exceed 1.6 J.
Time T corresponds to the minimum opening time (in seconds) until beginning of the open-
ing damping or until 80° C of door opening, or the minimum closing time (in seconds) from
90° C to 10° C of door opening (+ at least 1.5 s from 10° C to 0° C).
These times must be tested with appropriate measuring device (e.g. stop watch). The time
data is rounded on halve a second.
Door leaf weight [kg]
50 60 70 80 90 100 110 120 130 140 150 160
Width of door
leaf [mm]
Min. time T [s]
750 3.0 3.0 3.0 3.0 3.5 3.5 3.5 4.0 4.0 4.0 4.5 4.5
850 3.0 3.0 3.5 3.5 4.0 4.0 4.0 4.5 4.5 4.5 5.0 5.0
1000 3.5 3.5 4.0 4.0 4.5 4.5 5.0 5.0 5.5 5.5 5.5 6.0
1200 4.0 4.5 4.5 5.0 5.5 5.5 6.0 6.0 6.5
1300 4.5 4.5 5.0 5.5 5.5 6.0 6.5
1400 4.5 5.0 5.5 6.0 6.0 6.5
NOTICE
For parameter settings please see also chapter description of parameters!
