Configurations
16
102-127108955 V1.1 61/ 102
Configurations on the swing door operator can only be made with the electronic BDE-D, the
service- and flashprogrammer FPC 902 or the optional Testbox. If a toggle switch is con-
nected, the BDE-D, service- and flashprogrammer FPC 902 or Testbox must be connected
briefly for the configuration.
Please always leave the configuration review sheet in the drive even when the STG is re-
placed!
Description of parameters
W = Factory settings: Basic drive (FP)
PARAMETER W Comment
DRIVING CYCLE
→ Closing speed 20 Driving speed when closing the door.
0 = lowest speed
40 = highest speed
▪ The maximum reachable speed depends on the
driven distance (door width) and the acceleration set-
ting.
→ Opening speed 36 Driving speed of the opening door.
0 = lowest speed
40 = highest speed
▪ The maximum speed reachable depends upon the
opening angle and the acceleration setting.
▪ DIN: > 1.5 s <4 s
→ Acceleration 36
▪ Start-up acceleration while opening and closing the
door.
0 = low acceleration
40 = heavy acceleration
→ Creep drive 0 Early braking when closing increases the distance of door
travel with minimal closing speed in the range of the last past
20°.
0 = no creep drive
1 = creep for the last 2.5% of door travel
40 = 100%, i.e. creep for the entire door travel
(e.g. securing the upper shearing edge of the lintel)
→ Closing force 36 Increasing the motorised force during closing.
▪ DIN: 0
▪ If the value is higher than 0, a fixed safety sensor
must be installed in the closing direction!
TIME DELAYS OPEN
→ Time delay open 2 Determines the minimum time for which a door stays open
after it has been opened by a type AKA, AKI or automatic trig-
gering signal.
0..20 = 0 to 20 seconds, 1 s increments
16.2
