Interlock mode with 2 single-leaf doors
18
102-127108955 V1.1 86/ 102
NOTICE
The basic wiring for the interlock is always necessary. For following applications
additional wiring is necessary accordingly.
Deactivation of the interlock mode
The interlock mode is deactivated by the switch “Interlock-Off” (contact closed). This permits
to open the doors simultaneously.
Interlock sequence control
Without sensors inside the interlock
Installation A
Installation B
Options
Pushbutton inside the interlock
18.7
18.8
18.9
