Operating instructions DFA 127
14
102-127108955 V1.1 56/ 102
Operating modes and behaviour of the door during input signals
Table of signals (X marks a release reaction)
Explanation of the abbreviations see chapter
Abbreviations
Automatic / AUTO
Normal operation. The door opens and closes automatically, either by triggering of an activa-
tion device or by pushing the door, if the "touch control (push to activate)" is active.
CLOSED OPENING OPEN CLOSING
AKI X X X X
AKA X X X X
SSK X X X X
SIO X X X
SIS X X
TIPP X
Manual operation / HAND
In this mode the operator works as a normal door closer. It is easy to open the door by hand
and closes automatically. The actuating devices connected are ignored.
One-Way traffic / EXIT
In the One-Way traffic mode, people cannot enter the room from the outside, but can leave it
from the inside.
CLOSED OPENING OPEN CLOSING
AKI X X X X
AKA* X X X
SSK X X X X
SIO X X X
SIS X X
TIPP
* AKA is active as safety device while closing
Continuously open / OPEN
The door is opened and stays open. If an obstruction stands in the way while opening, the
operator tries another five times whithin a few seconds to bring the door to the target posi-
tion. Should the obstruction remain, the current position is then validated as the continuously
open position.
14.2.2
