Commissioning DFA 127
13
102-127108955 V1.1 53/ 102
Checking the LEDs on the STG
Check LED 1...3 according to the table in chapter
Controls on the STG 127
.
Checking the BDE functions and actuation devices
BDE-position (permanently open)
1. Door must open and remain open
2. Check the movement characteristics
3. Door cannot be moved by hand when open
BDE-position (locked)
1. Door must close
2. Check the movement characteristics
3. Check locking if present (see chapter
Status and fault signals BDE-D
)
4. Pressing
a second time initiates the SSK opening
5. SSK must release (if present)
6. AKI and AKA must not operate
BDE-position (one-way traffic)
1. AKI and SSK must operate
2. AKA must not be triggered when the door is closed
Programming door speeds and hold-open times
The functions are described in chapter
Operating instructions
.
Configuration of specific customer settings
The possibilities are described in chapter
Configurations
.
All modifications must be entered on the configuration sheet.
Safety check
1. BDE-position (automatic mode)
2. Open door (e.g. with AKI)
3. Operate a safety device while closing. Door must re-open.
4. The same check must be performed with every safety device present.
Checking automatic reverse
1. Obstruct door while closing. The door must reverse. When the door closes the next time
it moves at creep speed past the obstruction point.
2. Obstruct the door while opening. The door stops for hold-open time and closes. When
the door opens the next time it moves at creep speed past the obstruction point.
Touch control (push to actuate)
See about the configuration in chapter
Configurations
. By pressing lightly on the door, a
door-opening will be initiated.
Checking the functions of the DFA
▪ Check all the DFA functions
▪ Tighten the arm screw
Hand over to the client
▪ Instruct the client
▪ Hand over the operating manual
▪ RESET demonstration
13.4
13.5
13.6
13.7
13.8
13.9
13.10
13.11
13.12
