Commissioning DFA 127
13
102-127108955 V1.1 52/ 102
Operator Instructions Description
M+S Turn on the operator With Master/Slave-Installations turn on the
Slave first.
M Set the locking mechanism and door type
M Switch to manual mode With operation switch BDI
M+S If available, connect the sensor-bars SIO
and SIS.
These sensors should work properly, be-
cause they are adjusted during the calibra-
tion run.
M MF 3. light pulse Start calibration run
S MF 3. light pulse Start calibration run
M+S If present, connect the sensors and actua-
tors to AKI/AKA.
M+S Final setting of the operators
IMPORTANT
For Master / Slave-installation, also refer to chapter
Master / Slave Application
.
NOTICE
During the start-up procedure, it is important that no objects or persons are within
the passage.
CAUTION
Unexpected OPEN/CLOSE of the doors
• Bruises and contusions through the door leaf, or damages
The safety devices (sensors) are switched off during the learning cycle
(which must be only performed by trained personnel!) Before initiating the
learning cycle, it must therefore be ensured that no persons or objects are si-
tuated in the danger zone of the moving door leafes during operation.
CAUTION
Unexpected OPEN/CLOSE of the doors
• Bruises and contusions through the door leaf, or damages
In case of uncontrolled door motion, immediately disconnect the mains power
supply by turning off the main switch or unplugging the mains power plug.
