Commissioning DFA 127
13
102-127108955 V1.1 51/ 102
Legend:
M Master-operator
S Slave-operator
MF Multifunctional switch on controller
FPC record programming device (Flash-Programmer)
Operator Instructions Description
M+S Operators are turned off
M+S Adjust initial spring tension Procedure according to chapter
Adjustment
of the initial spring tension according to EN
4 to EN 6
and table in chapter
Door leaf
weights and door widths
M+S Check that the switch for direction of rota-
tion S1 is adjusted correctly
Settings according to chapter
Checking the
mechanical functions
The arms must not be connected to the
operator.
M+S Check that the CAN-connection has been
made over the CAN-insulation.
M Check that Jumper 14 is set to M1 on STG HW detection for Master STG
S Check that Jumper 14 is set to S1 on STG HW detection for Slave STG
M Switch operator to manual mode With operation switch BDI
M+S Turn on operators
M+S MF 8. light pulse Load default parameters
M MF 6. light pulse
FPC 902: Master / Diagnostic / Door pa-
rameters
Separate the arm from the operator!
Carry out the spring learning. Check the
spring value and re-adjust if necessary.
M FPC 902: Master / Parameter / Drive / Arms Check the correct settings of type of arms
S MF 6. light pulse
FPC 902: Master / Diagnostic / Door pa-
rameters
Separate the arm from the operator!
Carry out the spring teaching. Check the
spring value and re-adjust if necessary.
S FPC 902: Slave / Parameter / Drive / Arms Check the correct settings for the type of
arm
M+S Turn off the operator
M+S Mount arms Approx. 6° initial tension
M+S Check that the retarding effort while closing
without mains supply is correct.
