Configurations
16
102-127108955 V1.1 62/ 102
TIME DELAYS OPEN
21..40 = 22 to 60 seconds, 2 s increments
▪ The hold-open time starts only after all trigger and
safety signals have been made in the closing direc-
tion.
→ Time delay SSK 4 Determines the minimum time for which a door stays open
after it has been opened by a type SSK triggering signal.
0..20 = 0 to 20 seconds, 1 s increments
21..40 = 22 to 60 seconds, 2 s increments
▪ The hold-open time starts only after all trigger and
safety signals have been made in the closing direc-
tion.
NOTICE
The open duration can be reduced when sensors are used which keep the door
open, for example,
Time delay
with record sensors.
DRIVE
→ Opening angle 35 The opening angle is read during the learning cycle and corre-
sponds to the value 40.
0 = minimum opening angle
40 = maximum opening angle
▪ DIN: min. 95°
→ Collision CLOSED 20 Reaction point for collision detection during closing of the door.
0 = smooth
40 = rough
▪ The kinetic energy of the moving door is partially ab-
sorbed by the obstacle. According to its characteris-
tics, it takes a certain time for the controller to notice
the increase in force and reopen the door.
→ Collision OPEN 20 Reaction point for a collision detection during opening run (se-
condary closing edge).
0 = smooth
40 = rough
▪ The kinetic energy of the moving door is partially ab-
sorbed by the obstacle. According to its characteris-
tics, it takes a certain time for the controller to notice
the increase in force and stop the door.
