Configurations
16
102-127108955 V1.1 77/ 102
→ Locked The output signal shows whether the door is locked.
Output 0 V = door not locked.
Output 24 V = door closed and locked.
▪ The output is only set correctly for locking by VAK
signal.
→ Closed This output signal shows whether the door is closed.
Output 0 V = door not closed.
Output 24 V = door closed.
▪ The output may switch with a slight delay, i.e. when
closing only after the pressing phase and, when ope-
ning by hand, not before the door has opened by ap-
prox. 10 mm.
INPUT/OUTPUT --> FEM1
→ FEM type This parameter assigns the configurable input and output sig-
nals of the FEM1 to application-compatible default values.
→ Basic X All input and output signals are deactivated.
Configuration for interlock operation.
▪ It is possible to operate the system with sensors be-
tween the doors or without sensors with interlock se-
quential control.
Parameter Default value
Input → AUX10_IN S_AUS
Input → AUX11_IN SEA
Input → AUX12_IN SFS_IN
Output → AUX10_OUT SAA
Output → AUX11_OUT SAMP
→ Interlock
Output → AUX12_OUT SFS_OUT
→ AUX10_IN Configurable input signal for FEM1
Connector J1, terminals 64 & 65
Floating, optically disconnected 24V input
→ Disabled X
→ S_AUS Interlock control disabled.
▪ Both doors open at the same time by activation at
one side. SIS is active and stops the respective door.
