R8C/20 Group, R8C/21 Group 12. Interrupts

Rev.2.00 Aug 27, 2008 Page 93 of 458

REJ09B0250-0200

Figure 12.4 Registers TRD0IC, TRD1IC, SSUIC, and IICIC

Interrupt Control Register

(1)

Symbol Address After Reset

TRD0IC

0048h XXXXX000b

TRD1IC

0049h XXXXX000b

SSUIC/IICIC

(2)

004Fh XXXXX000b

Bit Symbol Bit Name Function RW

NOTES:

—

(b7-b4)

—

Nothing is assigned. If necessary, set to 0.

When read, the content is undefined.

Interrupt request bit 0 : Requests no interrupt

1 : Requests interrupt

ILV L0 RW

Interrupt priority level select bits

b2 b1 b0

0 0 0 : Level 0 (interrupt disable)

0 0 1 : Level 1

0 1 0 : Level 2

0 1 1 : Level 3

1 0 0 : Level 4

1 0 1 : Level 5

1 1 0 : Level 6

1 1 1 : Level 7

ILV L1 RW

ILV L2 RW

The IICSEL bit in the PMR register sw itches functions.

To rew rite the interrupt control register, rew rite it w hen the interrupt request w hich is applicable for its register is not

generated. Refer to

12.6.5 Changing Interrupt Control Register Contents

b7 b6 b5 b4 b3 b2 b1 b0
