R8C/20 Group, R8C/21 Group 16. Clock Synchronous Serial Interface
Rev.2.00 Aug 27, 2008 Page 295 of 458
REJ09B0250-0200
16.2.3 Interrupt Requests
Clock synchronous serial I/O with chip select has five interrupt requests: transmit data empty, transmit end,
receive data full, overrun error and conflict error. Since these interrupt requests are assigned to the clock
synchronous serial I/O with chip select interrupt vector table, determining interrupt sources by flags is required.
Table 16.3 shows the Clock Synchronous Serial I/O with Chip Select Interrupt Requests.
CEIE, RIE, TEIE and TIE: Bits in SSER register
ORER, RDRF, TEND and TDRE: Bits in SSSR register
Generation conditions of Table 16.3 are met, a clock synchronous serial I/O with chip select interrupt request is
generated. Set the each interrupt source to 0 by a clock synchronous serial I/O with chip select interrupt routine.
However, the TDRE and TEND bits are automatically set to 0 by writing the transmit data to the SSTDR
register and the RDRF bit is automatically set to 0 by reading the SSRDR register. When writing the transmit
data to the SSTDR register, at the same time the TDRE bit is set to 1 (data is transmitted from the SSTDR to
SSTRSR registers) again and when setting the TDRE bit to 0 (data is not transmitted from the SSTDR to
SSTRSR registers), additional 1-byte data may be transmitted.
Table 16.3 Clock Synchronous Serial I/O with Chip Select Interrupt Requests
Interrupt Request Abbreviation Generation Condition
Transmit Data Empty TXI TIE = 1, TDRE = 1
Transmit End TEI TEIE = 1, TEND = 1
Receive Data Full RXI RIE = 1, RDRF = 1
Overrun Error OEI RIE = 1, ORER = 1
Conflict Error CEI CEIE = 1, CE = 1
