15.2.1 Bit Rate
Divided-by-16 of frequency by the UiBRG (i = 0 or 1) register in UART mode is a bit rate.
Figure 15.12 Calculation Formula of UiBRG (i = 0 or 1) Register Setting Value
i = 0 or 1
Table 15.7 Bit Rate Setting Example in UART Mode (Internal Clock Selected)
Bit Rate
(bps)
UiBRG
Count
Source
System Clock = 20 MHz System Clock = 8 MHz
UiBRG
Setting Value
Actual Time
(bps)
Setting
Error(%)
UiBRG
Setting Value
Actual Time
(bps)
Setting
Error(%)
1200 f8 129 (81h) 1201.92 0.16 51 (33h) 1201.92 0.16
2400 f8 64 (40h) 2403.85 0.16 25 (19h) 2403.85 0.16
4800 f8 32 (20h) 4734.85 -1.36 12 (0Ch) 4807.69 0.16
9600 f1 129 (81h) 9615.38 0.16 51 (33h) 9615.38 0.16
14400 f1 86 (56h) 14367.82 -0.22 34 (22h) 14285.71 -0.79
19200 f1 64 (40h) 19230.77 0.16 25 (19h) 19230.77 0.16
28800 f1 42 (2Ah) 29069.77 0.94 16 (10h) 29411.76 2.12
31250 f1 39 (27h) 31250.00 0.00 15 (0Fh) 31250.00 0.00
38400 f1 32 (20h) 37878.79 -1.36 12 (0Ch) 38461.54 0.16
51200 f1 23 (17h) 52083.33 1.73 9 (09h) 50000.00 -2.34
<UART Mode>
• When selecting internal clock
Setting value to the UiBRG register =
fj
Bit Rate × 16
- 1
fj: Count source frequency of the UiBRG register (f1, f8 and f32)
• When selecting external clock
fEXT
Bit Rate × 16
- 1
fEXT: Count source frequency of the UiBRG register (external clock)
i = 0 or 1
Setting value to the UiBRG register =
