R8C/20 Group, R8C/21 Gro
up
14. T
imers
Rev
.2.00
Aug 27, 2008
Page 234 of 458
REJ09B0250-0200
Figure 14.96
Output Model of Comple
ment
ary PWM M
ode
Value in TRDi register
TRDIOD0 output
0000h
Value in TRDGRA0
register
Value in TRDGRB0
register
Value in TRDGRA1
register
Value in TRDGRB1
register
TRDIOB0 output
TRDIOC1 output
TRDIOA1 output
TRDIOD1 output
TRDIOB1 output
TRDIOC0 output
Value in TR
D0 register
Value in TRD1 register
i = 0 or
1
249
251
