R8C/20 Group, R8C/21 Group 14. Timers

Rev.2.00 Aug 27, 2008 Page 246 of 458

REJ09B0250-0200

Figure 14.107 Registers TRDGRAi, TRDGRBi, TRDGRCi and TRDGRDi in PWM3 Mode

The following registers are disabled in PWM3 mode:

TRDPMR, TRDDF0, TRDDF1, TRDIORA0, TRDIORC0, TRDPOCR0, TRDIORA1, TRDIORC1 and

TRDPOCR1

Timer RD General Register Ai, Bi, Ci and Di (i = 0 or 1)

(1)

Symbol Address After Reset

TRDGRA0

TRDGRB0

TRDGRC0

TRDGRD0

TRDGRA1

TRDGRB1

TRDGRC1

TRDGRD1

0149h-0148h

014Bh-014Ah

014Dh-014Ch

014Fh-014Eh

0159h-0158h

015Bh-015Ah

015Dh-015Ch

015Fh-015Eh

FFFFh

NOTE:

Function

Ref er to

Table 14.34 TRDGRji Register Functions in PWM3 Mode

Access the TRDGRAi to TRDGRDi registers in 16-bit units. Do not access them in 8-bit units.

b0b7

(b8)

(b15)

Default Chapter8
