R8C/20 Group, R8C/21 Group 10. Clock Generation Circuit
Rev.2.00 Aug 27, 2008 Page 66 of 458
REJ09B0250-0200
Figure 10.2 CM0 Register
System Clock Control Register 0
(1)
Symbol Address After Reset
CM0
0006h 01101000b
Bit Symbol Bit Name Function RW
NOTES:
1.
2.
3.
4.
5.
b7 b6 b5 b4 b3 b2 b1 b0
00100
—
(b1-b0)
Reserved bits Set to 0
RW
CM02
WAIT peripheral function clock stop
bit
0 : Peripheral function clock does not stop
in w ait mode
1 : Peripheral function clock stops in wait
mode
RW
—
(b3)
Reserved bit Set to 1
RW
—
(b4)
Reserved bit Set to 0
RW
CM05
XIN clock (XIN-XOUT) stop bit
(2,4)
0 : XIN clock oscillates
1 : XIN clock stops
(3)
RW
CM06
System clock division select bit 0
(5)
0 : Enables CM16, CM17
1 : Divide-by-8 mode
RW
—
(b7)
Reserved bit Set to 0
RW
When entering stop mode, the CM06 bit is set to 1 (divide-by-8 mode).
Set the PRC0 bit in the PRCR register to 1 (enables w riting) before rew riting to the CM0 register.
The CM05 bit is to stop the XIN clock w hen the high-speed on-chip oscillator mode, low -speed on-chip oscillator
mode is selected. Do not use this bit for w hether the XIN clock is stopped. To stop the XIN clock, set the bits in the
follow ing orders:
(a) Set the OCD0 and OCD1 bits in the OCD register to 00b.
(b) Set the OCD2 bit to 1 (selects on-chip oscillator clock).
During external clock input, only the clock oscillation buffer is turned off and clock input is acknow ledged.
P4_6 and P4_7 can be used as input ports w hen the CM05 bit is set to 1 (XIN clock stops) and the CM13 bit in the
CM1 register is set to 0 (P4_6, P4_7).
