4.2.5 Behavior during Low Power Mode
During the low power modes, different states apply for the ports and pins of the RH850/F1K series. The states depend
on the chosen low-power mode and may not have the same behavior for ports and pins.
• Port means that a pin works as a general-purpose input/output pin.
• Pin denotes the physical pin. Every pin is denoted by a unique pin number.
The following overview provides a summary of the port and pin behavior during low-power modes:
Table 12 Behavior during low power mode
State before entering the mode is kept
The ports are not powered and therefore not functional
I/O hold function for isolated area
During the DEEP STOP mode, the state of the port pins on the isolated area can be
held automatically. Thus, its input and/or output remain in the same state as before
entering I/O buffer hold state. No external or internal signal can change its state until
the I/O buffer hold state is terminated.
The I/O buffers in DEEP STOP mode are changing into I/O buffer hold state by
default.
After the wake-up from DEEP STOP mode the I/O buffer hold state is terminated in
the following steps:
o 1. Re-configure the peripheral or port function
o 2. Release I/O hold state by setting IOHOLD.IOHOLD = 0
