Renesas RH850/F1K Series User Manual

RH850/F1K Series Hardware Design Guide
R01AN2911EJ0100 Rev. 1.00 Page 36 of 46
Aug 04, 2016
6.1.2 Flash Programming Interface Connection of RH850/F1K Group
For the programming environment PG-FP5, the following connections are supported:
• Single-wire asynchronous flash programming interface
• Two-wire asynchronous flash programming interface
• Synchronous flash programming interface
For the programming environment combination of E1 emulator and RFP, the following connections are supported:
• Single-wire asynchronous flash programming interface
• Two-wire asynchronous flash programming interface
Table 22 Basic flash programming connection of RH850/F1K
Flash Programming Interface
Function
RH850/F1K Device Pins
1-wire UART
RxD/TxD
JP0_0
2-wire UART
RxD
JP0_0
TxD
JP0_1
CSI
SI
JP0_0
SO
JP0_1
SCK
JP0_2
