To reach the two lubricating nipples located on the stamp arm, it must be in the highest position. To reach
the two lubricating nipples on the pressure block of the cylinder, the stamp arm must be in the lowest
position.
Take care, dangerous movement.
A semi-central lubrication system can also be fitted as an option. The four lubricating nipples for the SS
bearing bushes are then moved to the side of the hard foil stamp, two of these lubricating nipples are
visible on Figure 9. Take note: the other six lubricating nipples must still be lubricated in the normal
manner, ie. manually.
Lubrication
Repak advises fully lubricating the stamps once a week. This lubricating scheme applies for machines
operating under normal operating conditions. The lubricating intervals must be adapted, depending on
conditions and operating intensity. If in doubt, consult the distributor.
