Setting Alarm and Recording Limits
23
Menu Option LCD Display Description of Option or Instructions Menu Path
Bradycardia
for Record
BRADY
RECORD LIMIT
BPM
Allows active waveforms to be recorded during a
bradycardia event prior to activation of the
Bradycardia alarm.
Values:
OFF, 50, 55, 60, 65, 70, 75, 80, 85, 90, 95, 100
beats per minute
Standard value: OFF
When in Event Mode and the Bradycardia Alarm
is set to 70 BPM and the Bradycardia for Record
is set to 80 BPM, the system will perform as
follows:
For a heart rate of >80 BPM, no waveforms will
be recorded and no alarm will occur.
For a heart of >70 BPM and <80 BPM,
waveforms will be recorded but no alarm will
occur.
For a heart rate of <70 BPM, waveforms will be
recorded and an alarm will occur.
All Menus
Record Menu
Pre/Post
Time
PRE/POST
TIME in seconds
This parameter allows the user to prescribe both
the number of seconds that waveforms are
recorded prior to the occurrence of a physiologic
event and after the event has terminated.
PRE defines the number of seconds that
waveforms will be recorded prior to the event.
POST defines the number of seconds that
waveforms will be recorded after the event has
terminated.
Values:
30/15, 30/60, 45/45, 60/30, 30/30, 75/15, 60/15,
45/15 seconds
Standard value: 30/15 seconds
All Menus
Record Menu
Impedance
Record?
RECORD
IMPEDANCE?
This parameter allows the user to select whether
or not the respiration waveform will be recorded.
Values:
YES or NO
Standard value: YES
All Menus
Record Menu
Record
Respiration
Rate
RECORD RESP
RATE?
This parameter allows the user to select whether
or not the Breath-To-Breath & the Average
Respiration Rates will be recorded.
Values:
YES or NO
Standard value: YES
All Menus
Record Menu
Heart rate
Record?
RECORD
HEARTRATE?
This parameter allows the user to select whether
or not the Beat-To-Beat & the Average Heart
Rates will be recorded.
Values:
YES or NO
Standard value: YES
All Menus
Record Menu
