4.2.8 Check Function
The Check Function can be used for two things:
When HART is used the DCS is warned that the analyzer is in maintenance/service, so values sent
to the DCS can be wrong values.
Another function is that a COM-port is configured for a service PC
4.2.9 Output mA range
Setting Output mA range is used to assign which value is corresponding to the 4 and 20mA range of the
analog output. As a consequence the analyzer (and mA out) will go into the out of specification status,
when the measured value will go out of these range. Screens below shows the menu and the pages where
the upper and lower range value can be set.
