9. Technical specifications
9.1 Operation characteristics
Density:
Resolution 0.2 g/l
Accuracy +/- 0.005 S.G.
Reproducibility 1 g/l
Range 700 g/l … 3000 g/l
HART 4-20mA Output (1x):
Resolution ± 0.002 % of FS
Repeatability ± 0.02 % of FS
Output current ± 4-20 mA into 250 Ω load
Interfaces:
Serial interface HART, USB
9.2 SDM housing
Dimensions (SDM, housing) Ø125x212 mm, (ØxL)
Dimensions (SDM, sensor tip) Ø60x65 + Ø25x(16/34/52/146/200) mm, (ØxL)
Display effective area 65x35 mm (WxH)
IP rating (with covers) IP 68
IP rating (without covers) IP 54
Ambient Temperature -5°C to +50°C
Relative humidity < 95% at 40ºC (noncondensing)
Display resolution and color 240x128 dots (WxH), 5 colors
Control push-buttons Pillow embossed metal dome, 4 pieces
Weight 6.4-6.8 kg
Power consumption maximum 8 W
Fuse (24 VDC) 5x20 mm, 630 mA (T)
Storage conditions -40°C to +75°C
---------------------------------------------------------------------------------------------------------------------------
Do not open the covers when circuits are alive in hazardous areas.
---------------------------------------------------------------------------------------------------------------------------
