Rhosonics SDM-4 - Installation

SDM – Slurry Density Meter
6 www.rhosonics.com
INSTALLATION
1.4 Document Issue
Document name (Rhosonics): 3A0-031-C56
Date
Issue
Description
11-11-2015
1
Concept
10-10-2016
A
Manual released
01-11-2016
B
Added chapter 9.3
05-12-2016
C
Compatible with software version V07.01.02.02
24-07-2017
C1
Updated operation for added functionality
2. Installation
2.1 Introduction
Purpose:
Installation of SDM unit, SDM adapters and cables.
The SDM is a 24 VDC powered standalone sensor with 4-20 mA output and HART protocol
Installation should be performed by skilled installation technicians (mechanical and electrical).
The SDM, which is installed in a specially prepared spool section, wafer section or is used in conjunction
with a pipe adapter (weldolet) has a ceramic sensor face which should be in contact with a representative
portion of the slurry to be measured.
IMPORTANT:
The surface of the ceramic front face must be aligned with the inside pipe diameter. Otherwise the SDM
will fail to measure correctly.
Installation:
 In chapter 2.1 and 2.2 there are common instructions for mounting the SDM adapter in a process
line. This chapter is valid for all sensor adapter types.
 In chapter 2.3 to chapter 2.5 the different SDM adapters mounting instructions are described. In
“Provided by Rhosonics” a description of the different types of SDM adapters.
 In chapter 2.6 the SDM mounting instructions are described.
CAUTION:
