14 June, 2002 SYSTEM FEATURES
6-67
Detailed
Descriptions
The meaning of the entries are described below.
Byte Information Meaning
03 Day
10 Hour
40 Minutes
Record the day and time. Here 03 10 40 means, the third day
of the month (30) at 10:40 a.m. (10 40).
2D Free – Not Used
2D Free – Not Used
2D Free – Not Used
These three bytes are not used. They record no information
about the operation log.
4B Operation
Records the operation. To identify the operation, see the
“Operation Breakdown Table” below.
31 Key Press
If “4B” followed by a 2-digit number is recorded, refer to the
“Key Press” table to identify the key
Operation Break Down HEX
Hard Key 4B**
On Hook 48 4F
Off Hook 48 46
Set original 44 4F
Removed original manually 44 46
Auto reset timer activates 54 4F
Power On 4F 4E
Simultaneous Press 53 49
** KEY PRESS ** KEY PRESS
01 Start 30
#
02 Stop 31
"
03 Copy Mode
↓ ↓
04 Initial Setting 39
$
09 Left Scroll 41 Quick Dial 001
0A Right Scroll 42 Quick Dial 002
0B Speed Dial
↓ ↓
0D Off Hook CF Quick Dial 143
0E Clear D0 Quick Dial 144
0F Group E0 F1 (User Function)
10 Reset E1 F2 (User Function)
14 Select 1
↓ ↓
15 Select 2 E8 F9 (User Function)
16 Select 3 E9 F10 (User Function)
17 Select 4 F0 Immediate Send/Memory Send
18 Network Address F3 Color Original/Photo Original
1D Clear Modes/Energy Saver F4 Darker/Normal/Lighter
1E
!%(press and hold)
F6 Standard/ Detail/ Super Fine/ Ex. Super Fine
1F Scan address F7 Internal Line/ G3/ G4
23
!
2A
%
2D Pause/Redial
