Ricoh Aficio MP C2550 Service Manual

Error Codes
D432/D433 16 SM
Code Meaning Suggested Cause/Action
Cable equalizer - G3 Switch 07 (PSTN)
Dedicated Tx parameters in Service Program
Mode
0-05
Modem training fails even
G3 shifts down to 2400
bps.
 Check the line connection.
 Try adjusting the tx level and/or cable
equalizer.
 Replace the FCU.
 Check for line problems.
Cross reference
See error code 0-04.
0-06
The other terminal did not
reply to DCS
 Check the line connection.
 Try adjusting the tx level and/or cable
equalizer settings.
 Replace the FCU.
 The other end may be defective or
incompatible; try sending to another machine.
 Check for line problems.
Cross reference
See error code 0-04.
0-07
No post-message
response from the other
end after a page was sent
 Check the line connection.
 Replace the FCU.
 The other end may have jammed or run out of
paper.
 The other end user may have disconnected
the call.
 Check for a bad line.
 The other end may be defective; try sending to
another machine.
0-08
The other end sent RTN or
PIN after receiving a page,
because there were too
many errors
 Check the line connection.
 Replace the FCU.
 The other end may have jammed, or run out of
paper or memory space.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
