Ricoh Aficio MP C2550 Service Manual

SC Tables
D037/D038/D040/D041 4-44 SM Appendix
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Tray lift motor error (D038/D041)
 Motor overload
 Loose connection of the tray lift motor
 Defective tray lift motor
750 B
1. Check the connections to the tray lift motor.
2. Replace the tray lift motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Finisher punch motor error (D038/D041)
The punch HP sensor is not activated within the specified time after the
punch motor turned on. The 1st detection failure issues a jam error, and
the 2nd failure issues this SC code.
 Punch HP sensor disconnected, defective
 Punch motor disconnected or defective
 Punch motor overload due to obstruction
760 D
1. Check the connections and cables for the punch motor and HP
sensor.
2. Check for blockages in the punch motor mechanism.
3. Replace the punch slider unit.
4. Replace the punch unit.
5. Replace the finisher main board.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Punch registration motor error (D038/D041)
The punch unit moves but is not detected at the home position within
the specified time. The 1st detection failure issues a jam error, and the
2nd failure issues this SC code.
763 B
 Motor harness disconnected, loose, defective

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
