Ricoh Aficio MP C2550 Service Manual

SC Tables
SM Appendix 4-45 D037/D038/D040/D041
Appendix:
Service Call
Conditions
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
 Defective registration motor
1. Check the connections to the punch registration motor.
2. Replace the punch unit slider.
3. Replace the punch unit.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Paper edge detection sensor error (D038/D041)
The machine does not detect correct voltage from the paper edge
detection sensor.
 Defective connector
 Defective paper edge detection sensor.
 Defective DA or AD converter.
787 D
1. Replace the punch slider unit.
2. Replace the punch unit.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
788 D Paper size sensor error without side tray (D038/D041)
789 B Paper size sensor error with side tray (D038/D041)
The machine does not detect correct voltage from the paper size
sensors.
 Defective connector
 Defective paper size sensors
 Defective DA or AD converter.
1. Replace the punch slider unit.
2. Replace the punch unit.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
