Ricoh Aficio MP C2550 Service Manual

SC Tables
D037/D038/D040/D041 4-52 SM Appendix
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
[3004] Command error
- -
When the main switch is turned on or starting the self-diagnostic, the
HDD stays busy for the specified time or more.
- -
 Loose connection
 Defective HDD
 Defective controller
- -
1. Check that the HDD is correctly connected to the controller.
2. Replace the HDD.
3. Replace the controller.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
823
CTL
B
Self-diagnostic error: NIB
[XXXX]: Detailed error code
[6101]
MAC address check sum error
The result of the MAC address check sum does not match the check
sum stored in ROM.
[6104]
PHY IC error
The PHY IC on the controller cannot be correctly recognized.
[6105]
PHY IC loop-back error
An error occurred during the loop-back test for the PHY IC on the
controller.
- Replace the controller.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
824
CTL
D
[1401]
Self-diagnosis error: Standard NVRAM
The controller cannot recognize the standard NVRAM installed or
detects that the NVRAM is defective.

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
