Ricoh Aficio MP C2550 Service Manual

SC Tables
SM Appendix 4-51 D037/D038/D040/D041
Appendix:
Service Call
Conditions
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Replace the controller board.
Self-diagnosis error: ASIC
The CPU checks if the ASIC timer works correctly compared with the
CPU timer. If the ASIC timer does not function in the specified range,
this SC code is displayed.
 System firmware problem
 Defective RAM-DIMM
 Defective controller
[0D05]
1. Reinstall the controller system firmware.
2. Replace the RAM-DIMM.
3. Replace the controller board.
Video bridge device error 1: ASIC
The CPU does not detects the video bridge device.
 Defective I/F between the video bridge device and i-controller
[50A1]
Replace the i-controller.
Video bridge device error 1: ASIC
The CPU detects the video bridge device, but detects error data from
the video bridge device..
 Defective I/F between the video bridge device and i-controller
[50A2]
Replace the i-controller.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
822
CTL
B
Self-diagnostic error: HDD (Hard Disk Drive)
[XXXX]: Detailed error code
[3003] Timeout error

Ricoh Aficio MP C2550 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	25 ppm
Print Speed (Monochrome)	25 ppm
Print Resolution	600 x 600 dpi
Maximum Print Resolution	2400 x 600 dpi
Duplex Printing	Yes
Copy Speed (Color)	25 cpm
Copy Speed (Monochrome)	25 cpm
Copy Resolution	600 x 600 dpi
Memory (Maximum)	1 GB
Hard Disk Drive (Optional)	80 GB
Interface	USB 2.0, Ethernet 10/100Base-TX
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A3
Scan Resolution	600 dpi
Zoom Range	25% - 400%
Paper Size	A4, A5, B5
Paper Weight	52 - 256 g/m²
PDL	PCL 6, PostScript 3
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS
