Adjusts magnification in the vertical direction, horizontal relative to the direction of paper
feed (sub scan direction).
[98 to 102/0.4% steps]
(14) CCD Main Regist M102, M103
Adjusts the scan start position in the vertical direction.
[-5 to 5/0.5 mm steps]
(15) CCD Sub Regist M102, M103
Adjusts the scan start position in the horizontal direction.
[-5 to 5/0.5 mm steps]
(16) ADF Sub Zoom M103 only
Adjusts the magnification of the image in the sub scan direction copied from an original fed
from the ADF.
[98 to 102/0.4% steps]
(17) ADF Main Regist M103 only
Adjusts the magnification of the image in the main scan direction copied from an original fed
from the ADF.
[-5 to 5/0.5 mm steps]
(18) ADF Sub Regist M103 only
Adjusts the magnification of the image in the main scan direction copied from an original fed
from the ADF.
[-5 to 5/0.5 mm steps]
(19) Counter Information
Counts are totaled for these items. Note that there are some differences, depending on the
machine.
Item M101 M102 M103
Print Total Yes Yes Yes
Utilities
175
