Ricoh Aficio SP 100SF

Sensors
Registration Sensor
Preparation
• Remove the AIO.
1. Raise the machine so you can see the bottom.
2. Disconnect the bottom plate and remove it ( x1).
3. Locate the registration sensor on the bottom of the machine.
Sensors
97
