Ricoh Aficio SP 100SF

Symbol What it means
Standoff
Stud screw
Tapping screw (wide threads for plastic)
Timing belt
Paper Feed: SEF/LEF
The notations "SEF" and "LEF" describe the direction of paper feed. The arrows indicate the direction of
paper feed.
In this manual "Main Scan" means "Horizontal" and "Sub Scan" means "Vertical", both relative to the
direction of paper feed.
Smart Organizing Monitor
In this service manual "Smart Organizing Monitor" is often abbreviated as "SOM".
