Ricoh Aficio SP 100SF

2. Locate the triangle marks that show you where the tab releases are located on the bottom.
3. Release the tabs on the bottom ( x3).
4. Separate the cover from the left side of the machine.
Rear Cover
The rear cover does not require removal unless the PSU requires replacement ( p.134 "PSU")
Basic Procedures
49
