Ricoh Aficio SP 100SF

Re-installation
1. Before you re-install the flatbed unit on top of the machine, insert the wide flat cable through the
ferrite plate.
• It is very difficult to thread this flat cable through the plate after setting the flatbed unit and ADF
on top of the machine.
Removing the Fusing Unit
Preparation
M101 ( p.43 "M101 Covers")
• AIO
• Front cover
Basic Procedures
71
