Image Problems
Overview
Image problems can occur at regular intervals [A] due to the different circumferences of rollers in the
machine and inside the AIO.
Diameter (mm) Interval (mm) Component
9.5 29.8 Charge Roller (AIO)
12 37.7 Development roller (AIO)
12.13 38.1 Relay roller
14.2 44.6 Exit Roller
14.6 45.8 Transfer roller
22 69.1 Pressure roller
23.96 75.2 Drum (AIO)
Image Problems
211
