PSU
Preparation
M101
• Front cover ( p.43 "M101 Covers")
• Right cover
M102
• Front cover (
p.50 "M102 Covers, Platen Cover, Flatbed Unit")
• Right cover
M103
• Front cover ( p.60 "M103 Covers, Flatbed Unit, ADF")
• Right cover
1. Open the clamps and free the harnesses ( x2).
