Paper Feed and Exit
This section describes how to remove these items:
• Pickup Roller
•
Friction Pad
• Paper Feed Roller
• Image Transfer Roller
• Exit Roller
Preparation
These items must be removed before doing any procedure in this section. Do this now before going to
any other part of this section.
M101
AIO (
p.43 "M101 Covers")
Front cover
Top cover
Right cover
Left cover
Laser unit (
p.81 "Removing the Laser Unit")
M102
AIO ( p.50 "M102 Covers, Platen Cover, Flatbed Unit")
Front cover
Top cover
Right cover
Left cover
Platen cover
Flatbed unit
Laser unit ( p.81 "Removing the Laser Unit")
M103
4. Replacement and Adjustments
86
