Ricoh Aficio SP 100SF

4. Use the tip of a small screw driver to release the tabs at [A], [B], [C] ( x3)
5. Open the top cover [A] to the right.
6. Disconnect the operation panel [B] , and then remove the cover ( x1).
Maintenance Cover
Preparation
Remove:
• Front cover
•
Top cover
4. Replacement and Adjustments
46
