• Left cover
M102 ( p.50 "M102 Covers, Platen Cover, Flatbed Unit")
• AIO
• Front cover
• Left cover
M103 (
p.60 "M103 Covers, Flatbed Unit, ADF")
• AIO
• Front cover
• Left cover
1. Release the power cord.
2. Disconnect the fusing unit harness [A]( x1)
3. Free the harness( s).
4. Pull the harness out of the harness guide.
4. Replacement and Adjustments
72
To Next Page
