Ricoh Aficio SP 100SF

2. Click the User Tool tab (1), open the List/Test pull-down list (2), and then click [Print]. The Test
Page prints.
3. Check the margins of the image area to see the width of the margins are satisfactory.
Margin Width (mm)
[A] Left 4.2
[B] Right 4.2
[C] Leading 4.2
[D] Trailing 4.2
4. Enter the service mode and display the Service Mode screen.
4. Replacement and Adjustments
84
