V.8 protocol on/off - G3 switch 03, bit2
1 0 0 9.6k
0 1 0 1 12.0k
0 1 1 0 14.4k
0 1 1 1 16.8k
1 0 0 0 19.2k
1 0 0 1 21.6k
1 0 1 0 24.0k
1 0 1 1 26.4k
1 1 0 0 28.8k
1 1 0 1 31.2k
1 1 1 0 33.6k
Other settings - Not used
4-5
Initial modem type for 9.6 k or 7.2
kbps.
Bit 5: 0, Bit 4: 0 = V.29
Bit 5: 0, Bit 4: 1 = V.17
Bit 5: 1, Bit 4: 0 = V.34
Bit 5: 1, Bit 4: 1 = Reserved
These bits set the initial modem type for 9.6 and 7.2 kbps,
if the initial modem rate is set at these speeds.
6-7 Not used Do not change the settings.
G3 Switch 06 [SP No. 1-105-007]
No FUNCTION COMMENTS
0-3
Initial Rx modem rate • These bits set the initial starting modem rate for
reception.
• Use a lower setting if high speeds pose
problems during reception.
• If a modem rate 14.4 kbps or slower is
selected, V.8 protocol should be disabled
manually.
Cross reference:
Bit 3 Bit 2 Bit 1 Bit 0 bps
0 0 0 1 2.4k
0 0 1 0 4.8k
0 0 1 1 7.2k
Bit Switches
81
